Easy operation vertical lifting man lift platform for cleaning
| Price: | 2015.0 USD |
| Payment Terms: | T/T |
| Place of Origin: | Shandong, China (Mainland) |
|
|
| Add to Basket | Add to My Favorites |
| HiSupplier Escrow |
Product Detail
Anti skid
Emergency decline valve
overload protection
Low noise
safety and reliability
Specifications
Anti skid
Emergency decline valve
overload protection
Low noise
safety and reliability
Product Description
Control System
1.Electric control:
A.manual button box, which may be placed on the platform for the convenience of operation.
B.electric control box, which is supported with emergency stop button for prevention of any accident.
2.Manual control: It can install manual lowering valve, in case of power cut off suddenly.
Single mast
Aluminum Alloy Hydraulic Platform | |||||||||||||||||||||||||||||||||||||||||
Model | Lifting height(m) | Lifting weight(kg) | Platform size(mm) | Overall dimension (mm) | Power supply(kw) | Total weight(kg) | |||||||||||||||||||||||||||||||||||
SJL0.10-4 | 4 | 100 | 550*550 | 1200*750*1980 | 1.1 | 200 | |||||||||||||||||||||||||||||||||||
SJL0.10-6 | 6 | 100 | 550*550 | 1200*750*1980 | 1.1 | 230 | |||||||||||||||||||||||||||||||||||
SJL0.10-8 | 8 | 100 | 550*550 | 1250*830*1980 | 1.1 | 280 | |||||||||||||||||||||||||||||||||||
SJL0.10-9.6 | 9.6 | 100 | 550*550 | 1350*830*1980 | 1.1 | 300 | |||||||||||||||||||||||||||||||||||
SJL0.10-10 | 10 | 100 | 550*550 | 1350*830*1980 | 1.1 | 320 | |||||||||||||||||||||||||||||||||||
Double Track Aluminum Alloy Hydraulic Platform | |||||||||||||||||||||||||||||||||||||||||
Model | Lifting height(m) | Lifting weight(kg) | Platform size(mm) | Overall dimension(mm) | Power supply(kw) | Total weight(kg) | |||||||||||||||||||||||||||||||||||
SJL0.2-6 | 6 | 200 | 1200*600 | 1350*870*1980 | 1.5 | 450 | |||||||||||||||||||||||||||||||||||
SJL0.2-8 | 8 | 200 | 1250*600 | 1450*870*1980 | 1.5 | 550 | |||||||||||||||||||||||||||||||||||
SJL0.2-10 | 10 | 200 | 1400*600 | 1600*870*1980 | 1.5 | 650 | |||||||||||||||||||||||||||||||||||
SJL0.2-12 | 12 | 200 | 1500*600 | 1700*920*1980 | 1.5 | 700 | |||||||||||||||||||||||||||||||||||
SJL0.2-14 | 14 | 200 | 1550*650 | 1900*1200*2400 | 1.5 | 660 | |||||||||||||||||||||||||||||||||||
SJL0.2-16 | 16 | 200 | 1550*650 | 1900*1200*2700 | 2.2 | 700 | |||||||||||||||||||||||||||||||||||
Three mast
Model | Lifting height (m) | capacity (kg) | Table size (mm) | Total dimension (L * W * H) mm | Mating Power (kw) | Net weight (kg) |
SJL0.2-12 | 12 | 200 | 1550 * 750 | 1880*1200*1980 | 2.2 | 900 |
SJL0.2-14 | 14 | 200 | 1550 * 750 | 1900*1400*2600 | 2.2 | 1000 |
SJL0.2-16 | 16 | 200 | 1550 * 750 | 1900*1400*2700 | 2.2 | 1250 |
SJL0.2-18 | 18 | 200 | 1700 * 750 | 2100*1400*2800 | 2.2 | 1500 |
Tiltable three mast | 16m/3100*1200*2000(put down) 18m/3200*1200*2200(put down) | |||||
Advantages
1.It is the best and safest partner in maintaining machines and tools, painting and decoration, changing lights, electric appliances and cleaning.
2.it can be operated up and down.
3.It is equipped with security rope and safety protection devices.
4.It can be in and out of the elevators conveniently when equipped with belt control switch or remote control switch systems.
5.Compact structure, small size, can enter narrow and small area.
Our Services
1. All the machines will be full tested before shipment
2. The total machine guarantee is 12 moths
3. 24 Hours technical support, email, telephone or video online
4. User-friendly English manual for machine using and maintaining
We are a professional manufacturer of kinds of Hydraulic Lift in China. Welcome to visit our website www.cntruewin.com for more details
Company Information
Shan Dong True Win Construction Material Co.,Ltd is a professional manufacturer of aerial working platforms,logistics equipments and handling equipment for logistics ,Our company main products are: Mobile scissor lift, Self-propelled scissor lift, Stationary scissor lift, Aluminum alloy lift , Crank arm type lift, Guide rail lift, and Hydraulic yard ramp,have 8 series and more than 60 varieties. They are widely used for many industries such as plant maintenance, industrial installation, equipment's repair and maintenance, property management, warehouse, airport, port, station, gas station, stadium, museum, exhibition hall. all of our products have passed the detection of Check station of China Special Equipment and Manufacture License of Special Equipment of People's Republic of China and also has passed ISO9001-2000 quality system certification , the quality and performance of our products have won acceptance,all its products are not only sold well at home, but also exported to 30 countries around the world,mainly in Europe , south-Africa ,middle-east,south-east Asia,USA and south-Afr ica.Our products can fully meet the needs of different customers ,If you are interested in our products, please feel free to contact us for more information.we will be your the best reliable friend with our complete product range, excellent product quality and best sales services.
